UniFi Dream Machine Special Edition UDM-SE (172W)

UniFi Dream Machine Special Edition UDM-SE (172W)

Technical Specifications

Mechanical

• Dimensions:442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″)
• Weight: 10.9 lb
• Enclosure Materials: Aluminium CNC, SGCC steel
• Mount Material: SGCC Steel

Hardware

• Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
• System Memory: 4 GB DDR4
• On-board Storage: 16 GB eMMC | Integrated 128 GB SSD
• Management Interface: Ethernet | Bluetooth
• Networking Interface: (8) LAN: GbE RJ45 Ports | (1) WAN: 2.5 GbE RJ45 port
• SFP+ Interface: (1) LAN: 10G SFP+ | (1) WAN: 10G SFP+
• PoE interface: (6) PoE (Pair A 1, 2+; 3, 6-) | (2) PoE+ (Pair A 1, 2+; 3, 6-)
• IDS/IPS Throughput: 3.5 Gbps* (*Measured with iPerf3)
• Power Method: (1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz | (1) USP-RPS DC Input, 52V DC, 3.94A
• Power Supply: AC/DC, internal, 240W
• Supported Voltage Range: 100—240V AC
• Max. Power Consumption: 50W (Excluding PoE output)
• Max. PoE Wattage per Port by PSE: oE: 15.4W | PoE+: 30W
• Voltage Range PoE Mode: PoE: 44—57V | PoE+: 50—57V
• ESD/EMP Protection: Air: ± 15kV, Contact: ± 8kV
• LCM Display: (1) 1.3″ Touchscreen
• Button: Factory Reset
• Operating Temperature: -10 to 40° C (14 to 104° F)
• Operating Humidity: 5 to 95% noncondensing
• Certifications: CE, FCC, IC

LEDs

• Ethernet: White: link/activity
• SFP+: White: link/activity
• HDD: White: disk activity | Amber: disk error
• RPS: Blue: ready
